السَّلاَمُ عَلَيْكُمْ وَرَحْمَةُ اللهِ وَبَرَكَاتُهُ
apa kabar semua ? ^_^
berjumpa lagi dengan saya, admin codingpintar ^_^
semoga sehat semua yah, dan masih semangat untuk belajar codingnya heheh ^_^
nah, pada kesempatan kali ini saya akan memberikan tutorial Cara Membuat Karakter Dengan CSS3
Kalau pada tutorial sebelumnya Karakter yang saya buat yaitu Karakter Minion Pure CSS yang bisa anda lihat DISINI atau karakter Spongebob Pure CSS yang bisa anda lihat DISINI
nah pada kesempatan kali ini saya akan membuat karakter Kartun Doraemon Pure CSS .
Seperti biasanya karakter yang saya buat ini hanya menggunakan css3, dan seperti karakter sebelumnya karakter ini bukan buatan saya melainkan seorang web programming yang saya sendiri belum tau namanya .
karya dia sengaja saya share disini agar kita semua bisa tau
cara membuat karakter dengan css3.
tidak usah nerlama-lama lagi, silahkan ikuti langkah-langkah di bawah ini dengan benar.
1. Membuat File HTML
seperti biasa silahkan anda siapkan file HTML bernama index.html,
lalu ketikkan script berikut ini .
<!DOCTYPE html>
<head>
<meta charset="utf-8">
<link rel="stylesheet" type="text/css" href="dora.css">
</head>
<body>
<div id="doraemon">
<div id="face">
<div id="head_light"></div>
<div id="eyes">
<div class="eye eye_left"></div>
<div class="black_eye black_left"></div>
<div class="eye eye_right"></div>
<div class="black_eye black_right"></div>
</div>
<div id="base">
<div id="base_white"></div>
<div id="nose">
<div id="nose_light"></div>
</div>
<div id="nose_line"></div>
<div id="mouth"></div>
<div id="mouth_rewrite"></div>
<div id="firefox_mouth"></div>
<div class="whiskers whi_right_top rotate160"></div>
<div class="whiskers whi_right"></div>
<div class="whiskers whi_right_bottom rotate20"></div>
<div class="whiskers whi_left_top rotate20"></div>
<div class="whiskers whi_left"></div>
<div class="whiskers whi_left_bottom rotate160"></div>
</div>
</div>
<div id="choker">
<div id="belt"></div>
<div id="bell">
<div id="bell_line"></div>
<div id="bell_circle"></div>
<div id="bell_under"></div>
<div id="bell_light"></div>
</div>
</div>
<div id="body">
<div id="doutai"></div>
<div class="base_white2 doutai_center"></div>
<div id="pocket">
<div id="circle"></div>
<div id="circle_rewrite"></div>
</div>
</div>
<div id="hand_right">
<div id="arm_right"></div>
<div class="hand_circle hand_right"></div>
<div class="arm_rewrite_right"></div>
</div>
<div id="hand_left">
<div id="arm_left"></div>
<div class="hand_circle hand_left"></div>
<div class="arm_rewrite_left"></div>
</div>
<div id="foot">
<div id="foot_left"></div>
<div id="foot_right"></div>
<div id="foot_rewrite"></div>
</div>
<div id="shadow_doutai_arm"></div>
<div id="shadow_doutai_left"></div>
<div id="shadow_doutai_right"></div>
<div id="shadow_belt"></div>
</div>
</body>
</html>
jika file htmlnya sudah anda buat coba anda jalankan telebih dulu,
ya benar hasilkan akan blank atau tidak ada apa-apa, itu di karenakan kita belum membuat file cssnya, Silahkan ikuti langkah selanjutnya
2. Membuat File CSS
file css inilah file yang ter penting hehe ^_^, silahkan buat file cssnya bernama style.css, dan ketikkan script berikut .
#doraemon {
position:relative;
margin:50px;
float:left;
width:500px;
}
#instr {
float:right;
width:400px;
font-size:14px;
border-left:2px solid black;
padding-left:20px;
}
#head_light {
width:50px;
height:50px;
transform: rotate(20deg);
-webkit-transform: rotate(20deg);
-moz-transform: rotate(20deg);
-o-transform: rotate(20deg);
box-shadow:80px 20px 50px #fff;
-webkit-box-shadow:80px 20px 55px #fff;
-moz-box-shadow:80px 20px 50px #fff;
border-radius:45px;
-webkit-border-radius:45px;
-moz-border-radius:60px;
position:absolute;
top:-20px;
left:170px;
opacity:0.5
}
#face {
position:relative;
width:310px;
height:300px;
border-radius:146px;
-webkit-border-radius:146px;
-moz-border-radius:146px;
background:#07beea;
background: -webkit-gradient(linear, right top, left bottom, from(#fff), color-stop(0.20, #07beea), color-stop(0.73, #10a6ce), color-stop(0.95, #000), to(#444));
background: -moz-linear-gradient(right top, #fff, #07beea 20%, #10a6ce 73%, #000 95%, #000 155%);
border:#333 2px solid;
top:-15px;
box-shadow:-5px 10px 15px rgba(0, 0, 0, 0.45);
-webkit-box-shadow:-5px 10px 15px rgba(0, 0, 0, 0.45);
-moz-box-shadow:-5px 10px 15px rgba(0, 0, 0, 0.45);
}
#base {
position:relative;
top:-5px;
}
#base_white {
position:absolute;
border:#000 2px solid;
width:264px;
height:196px;
border-radius: 150px 150px;
-webkit-border-radius: 150px 150px;
-moz-border-radius: 150px 150px;
background:#FFF;
background: -webkit-gradient(linear, right top, left bottom, from(#fff), color-stop(0.75, #fff), color-stop(0.83, #eee), color-stop(0.90, #999), color-stop(0.95, #444), to(#000));
background: -moz-linear-gradient(right top, #fff, #fff 75%, #eee 83%, #999 90%, #444 95%, #000);
z-index:1;
top:85px;
left:22px;
}
#eyes {
position:relative;
top:-5px;
}
div.eye {
position:absolute;
border-radius: 35px 35px;
-webkit-border-radius: 35px 35px;
-moz-border-radius: 35px 35px;
border:2px solid #000;
width:72px;
height:83px;
z-index:20;
background:#fff;
}
div.black_eye {
position:absolute;
width:15px;
height:15px;
border-radius:10px;
-webkit-border-radius:10px;
-moz-border-radius:10px;
background:#333;
z-index:21;
-webkit-animation-name: cate;
-webkit-animation-duration: 3s;
-webkit-animation-timing-function: linear;
-webkit-animation-iteration-count: 200;
}
@-webkit-keyframes cate {
0% {
margin:0 0 0 0;
}
80% {
margin:0px 0 0 0;
}
85% {
margin:-20px 0 0 0;
}
90% {
margin:0 0 0 0;
}
93% {
margin:0 0 0 7px;
}
96% {
margin:0 0 0 0;
}
100% {
margin:0 0 0 0;
}
}
div.black_left {
top:100px;
left:130px;
}
div.black_right {
top:100px;
left:170px;
}
div.eye_left {
top:45px;
left:82px;
}
div.eye_right {
top:45px;
left:156px;
}
#nose {
width:32px;
height:32px;
border:2px solid #000;
border-radius:50px;
-webkit-border-radius:50px;
-moz-border-radius:50px;
background:#c93e00;
position:absolute;
top:117px;
left:139px;
z-index:30;
}
#nose_light {
width:10px;
height:10px;
border-radius:5px;
-webkit-border-radius:5px;
-moz-border-radius:5px;
box-shadow:19px 8px 5px #fff;
-webkit-box-shadow:19px 8px 5px #fff;
-moz-box-shadow:19px 8px 5px #fff;
position:relative;
top:0px;
left:0px;
}
#nose_line {
background:#000;
width:4px;
height:100px;
top:125px;
left:156px;
position:absolute;
}
#nose_line {
background:#333;
width:3px;
height:100px;
top:140px;
left:155px;
position:absolute;
z-index:20;
}
#mouth {
width:240px;
height:500px;
border-bottom:3px solid #333;
border-radius:120px;
-webkit-border-radius:120px;
-moz-border-radius:120px;
position:absolute;
top:-263px;
left:36px;
z-index:10;
}
#mouth_rewrite {
background:#fff;
width:240px;
height:90px;
position:relative;
top:115px;
left:35px;
z-index:12;
border-radius:45px;
-webkit-border-radius:45px;
-moz-border-radius:60px;
}
#firefox_mouth, x:-moz-broken, x:last-of-type, x:indeterminate {
position:relative;
width:170px;
height:150px;
-moz-border-radius:85px;
border:3px solid #000;
background:#FFF;
z-index:11;
top:-3px;
left:70px;
}
.whiskers {
background:#333;
height:2px;
width:60px;
position:absolute;
z-index:20;
}
.whi_right {
top:165px;
left:210px;
}
.whi_right_top {
top:145px;
left:210px;
}
.whi_right_bottom {
top:185px;
left:210px;
}
.whi_left {
top:165px;
left:50px;
}
.whi_left_top {
top:145px;
left:50px;
}
.whi_left_bottom {
top:185px;
left:50px;
}
.rotate20 {
transform: rotate(20deg);
-webkit-transform: rotate(20deg);
-moz-transform: rotate(20deg);
-o-transform: rotate(20deg);
}
.rotate160 {
transform: rotate(160deg);
-webkit-transform: rotate(160deg);
-moz-transform: rotate(160deg);
-o-transform: rotate(160deg);
}
#choker {
position:relative;
top:-55px;
left:35px;
z-index:100;
}
#belt {
width:230px;
height:20px;
border:#000 solid 2px;
background:#ca4100;
background: -webkit-gradient(linear, left top, left bottom, from(#ca4100), to(#800400));
background: -moz-linear-gradient(top, #ca4100, #800400);
border-radius:10px;
-webkit-border-radius:10px;
-moz-border-radius:10px;
position:relative;
left:5px;
}
#bell {
width:40px;
height:40px;
border-radius:50px;
-webkit-border-radius:50px;
-moz-border-radius:50px;
border:2px solid #000;
background:#f9f12a;
background: -webkit-gradient(linear, left top, left bottom, from(#f9f12a), color-stop(0.5, #e9e11a), to(#a9a100));
background: -moz-linear-gradient(top, #f9f12a, #e9e11a 75%, #a9a100);
box-shadow:-5px 5px 10px rgba(0, 0, 0, 0.25);
-webkit-box-shadow:-5px 3px 5px rgba(0, 0, 0, 0.25);
-moz-box-shadow:-5px 5px 10px rgba(0, 0, 0, 0.25);
position:relative;
top:-15px;
left:100px;
}
#bell_line {
width:36px;
height:2px;
background:#f9f12a;
border:#333 solid 2px;
position:relative;
top:10px;
}
#bell_circle {
width:12px;
height:10px;
border-radius:5px;
-webkit-border-radius:5px;
-moz-border-radius:5px;
background:#000;
position:relative;
top:14px;
left:14px;
}
#bell_under {
width:3px;
height:15px;
background:#000;
position:relative;
top:10px;
left:18px;
}
#bell_light {
width:10px;
height:10px;
border-radius:10px;
-webkit-border-radius:10px;
-moz-border-radius:10px;
box-shadow:19px 8px 5px #fff;
-webkit-box-shadow:19px 8px 5px #fff;
-moz-box-shadow:19px 8px 5px #fff;
position:relative;
opacity:0.7;
top:-35px;
left:5px;
}
#doutai {
position:absolute;
width:220px;
height:165px;
background:#07beea;
background: -webkit-gradient(linear, right top, left top, from(#07beea), color-stop(0.5, #0073b3), color-stop(0.75, #00b0e0), to(#0096be));
background: -moz-linear-gradient(right, #07beea, #0073b3 50%, #0096be 75%, #00b0e0, #0096be 100%, #333 114%);
border:#333 2px solid;
top:262px;
left:46px;
}
div.base_white2 {
position:absolute;
width:170px;
height:170px;
border-radius:85px;
-webkit-border-radius:85px;
-moz-border-radius:85px;
border:2px solid #000;
background:#FFF;
background: -webkit-gradient(linear, right top, left bottom, from(#fff), color-stop(0.75, #fff), color-stop(0.83, #eee), color-stop(0.90, #999), color-stop(0.95, #444), to(#000));
background: -moz-linear-gradient(right top, #fff, #fff 75%, #eee 83%, #999 90%, #444 95%, #000);
}
.doutai_center {
top:230px;
left:72px;
}
#circle {
position:relative;
width:130px;
height:130px;
border-radius:65px;
-webkit-border-radius:65px;
-moz-border-radius:65px;
background:#fff;
background: -webkit-gradient(linear, right top, left bottom, from(#fff), color-stop(0.70, #fff), color-stop(0.75, #f8f8f8), color-stop(0.80, #eee), color-stop(0.88, #ddd), to(#fff));
background: -moz-linear-gradient(right top, #fff, #fff 70%, #f8f8f8 75%, #eee 80%, #ddd 88%, #fff);
border:2px solid #000;
top:-120px;
left:92px;
}
#circle_rewrite {
position:relative;
width:134px;
height:60px;
background:#fff;
border-bottom:2px solid #000;
top:-250px;
left:92px;
}
#hand_right {
position:absolute;
top:272px;
left:248px;
width:100px;
height:100px;
}
#arm_right {
position:relative;
width:80px;
height:50px;
background:#07beea;
background: -webkit-gradient(linear, left top, left bottom, from(#07beea), color-stop(0.85, #07beea), to(#555));
background: -moz-linear-gradient(top, #07beea, #07beea 85%, #555);
border:solid 1px #000;
z-index:-1;
top:17px;
transform: rotate(35deg);
-webkit-transform: rotate(35deg);
-moz-transform: rotate(35deg);
-o-transform: rotate(35deg);
box-shadow:-10px 7px 10px rgba(0, 0, 0, 0.35);
-webkit-box-shadow:-10px 7px 10px rgba(0, 0, 0, 0.35);
-moz-box-shadow:-10px 7px 10px rgba(0, 0, 0, 0.35);
}
#hand_left {
position:absolute;
top:272px;
left:-46px;
width:100px;
height:100px;
}
#arm_left {
position:relative;
width:80px;
height:50px;
background:#0096be;
border:solid 1px #000;
z-index:-1;
top:17px;
left:36px;
transform: rotate(145deg);
-webkit-transform: rotate(145deg);
-moz-transform: rotate(145deg);
-o-transform: rotate(145deg);
box-shadow:5px -7px 10px rgba(0, 0, 0, 0.25);
-webkit-box-shadow:5px -7px 10px rgba(0, 0, 0, 0.25);
-moz-box-shadow:5px -7px 10px rgba(0, 0, 0, 0.25);
}
div.hand_circle {
position:absolute;
width:60px;
height:60px;
border-radius:30px;
-webkit-border-radius:30px;
-moz-border-radius:30px;
border:2px solid #000;
background:#fff;
background: -webkit-gradient(linear, right top, left bottom, from(#fff), color-stop(0.5, #fff), color-stop(0.70, #eee), color-stop(0.8, #ddd), to(#999));
background: -moz-linear-gradient(right top, #fff, #fff 50%, #eee 70%, #ddd 80%, #999);
}
.hand_right {
top:32px;
left:40px;
}
.arm_rewrite_right {
position:relative;
width:4px;
height:45px;
background:#07beea;
top:-51px;
left:18px;
}
.hand_left {
top:34px;
left:10px;
}
.arm_rewrite_left {
position:relative;
width:4px;
height:50px;
background:#0096be;
top:-52px;
left:92px;
}
#foot {
position:relative;
width:280px;
height:40px;
top:-141px;
left:20px;
}
#foot_left {
width:125px;
height:30px;
background:#fff;
background: -webkit-gradient(linear, right top, left bottom, from(#fff), color-stop(0.75, #fff), color-stop(0.85, #eee), to(#999));
background: -moz-linear-gradient(right top, #fff, #fff 75%, #eee 85%, #999);
border:solid 2px #333;
border-top-left-radius:80px;
border-bottom-left-radius:40px;
border-top-right-radius:60px;
border-bottom-right-radius:60px;
-webkit-border-top-left-radius:80px;
-webkit-border-bottom-left-radius:40px;
-webkit-border-top-right-radius:60px;
-webkit-border-bottom-right-radius:60px;
-moz-border-radius-topleft:80px;
-moz-border-radius-bottomleft:40px;
-moz-border-radius-topright:60px;
-moz-border-radius-bottomright:60px;
position:relative;
left:8px;
top:2px;
box-shadow:-6px 0px 10px rgba(0, 0, 0, 0.35);
-webkit-box-shadow:-6px 0px 10px rgba(0, 0, 0, 0.35);
-moz-box-shadow:-6px 0px 10px rgba(0, 0, 0, 0.35);
z-index:-1;
}
#foot_right {
position:relative;
width:125px;
height:30px;
background:#fff;
background: -webkit-gradient(linear, right top, left bottom, from(#fff), color-stop(0.75, #fff), color-stop(0.85, #eee), to(#999));
background: -moz-linear-gradient(right top, #fff, #fff 75%, #eee 85%, #999);
border:solid 2px #333;
border-top-left-radius:60px;
border-bottom-left-radius:60px;
border-top-right-radius:80px;
border-bottom-right-radius:40px;
-webkit-border-top-left-radius:60px;
-webkit-border-bottom-left-radius:60px;
-webkit-border-top-right-radius:80px;
-webkit-border-bottom-right-radius:40px;
-moz-border-radius-topleft:60px;
-moz-border-radius-bottomleft:60px;
-moz-border-radius-topright:80px;
-moz-border-radius-bottomright:40px;
top:-32px;
left:141px;
box-shadow:-6px 0px 10px rgba(0, 0, 0, 0.35);
-webkit-box-shadow:-6px 0px 10px rgba(0, 0, 0, 0.35);
-moz-box-shadow:-6px 0px 10px rgba(0, 0, 0, 0.35);
z-index:-1;
}
#foot_rewrite {
position:relative;
width:20px;
height:10px;
background:#fff;
background: -webkit-gradient(linear, right top, left bottom, from(#666), color-stop(0.83, #fff), to(#fff));
background: -moz-linear-gradient(right top, #666, #fff 83%, #fff);
top:-76px;
left:127px;
border-top:2px solid #000;
border-right:2px solid #000;
border-left:2px solid #000;
border-top-right-radius:40px;
border-top-left-radius:40px;
-webkit-border-top-right-radius:40px;
-webkit-border-top-left-radius:40px;
-moz-border-radius-topleft:40px;
-moz-border-radius-topright:40px;
}
#shadow_doutai_left {
width:30px;
height:200px;
box-shadow:-10px 10px 15px rgba(0, 0, 0, 0.45);
-webkit-box-shadow:-10px 10px 15px rgba(0, 0, 0, 0.45);
-moz-box-shadow:-10px 10px 15px rgba(0, 0, 0, 0.45);
position:absolute;
top:250px;
left:46px;
z-index:-10;
}
#shadow_doutai_right {
width:30px;
height:200px;
box-shadow:10px 10px 15px rgba(0, 0, 0, 0.35);
-webkit-box-shadow:10px 10px 25px rgba(0, 0, 0, 0.35);
-moz-box-shadow:10px 10px 15px rgba(0, 0, 0, 0.35);
position:absolute;
top:240px;
left:230px;
z-index:-10;
}
#shadow_doutai_arm {
width:85px;
height:165px;
box-shadow:-100px 10px 15px rgba(0, 0, 0, 0.0);
-webkit-box-shadow:-100px 10px 15px rgba(0, 0, 0, 0.25);
-moz-box-shadow:-100px 10px 15px rgba(0, 0, 0, 0.25);
position:absolute;
top:230px;
left:113px;
z-index:10;
opacity:0.5;
transform: rotate(-20deg);
-webkit-transform: rotate(-20deg);
-moz-transform: rotate(-20deg);
-o-transform: rotate(-20deg);
border-bottom-left-radius:40px;
-webkit-border-bottom-left-radius:40px;
-moz-border-radius-bottomleft:40px;
border-top-left-radius:20px;
-webkit-border-top-left-radius:20px;
-moz-border-radius-topleft:20px;
}
#shadow_belt {
width:40px;
height:30px;
box-shadow:-100px 10px 15px rgba(0, 0, 0, 0);
-webkit-box-shadow:-100px 10px 15px rgba(0, 0, 0, 0.25);
-moz-box-shadow:-100px 10px 15px rgba(0, 0, 0, 0.25);
position:absolute;
top:240px;
left:130px;
z-index:10;
border-bottom-left-radius:40px;
-webkit-border-bottom-left-radius:40px;
-moz-border-radius-bottomleft:40px;
z-index:300;
}
#arm_left:not(\*|*), .arm_rewrite_left:not(\*|*) {
background:#07beea;
}
#arm_left, .arm_rewrite_left {
background:#07beea\9;
*background:#07beea;
_background:#07beea;
}
#kiji {
position:relative;
top:-150px;
}
ternyata banyak juga ya script cssnya heheh,
nah coba deh anda jalankan file index.htmlnya dan lihat di browser anda
PENTING :
Karakter ini akan terlihat sempurna apabila di jalankan di google chrome atau opera versi terbaru.
ya sudah mungkin itu dulu yang dapat saya sampaikan, :)
silahkan anda coba dan anda kembangkan sendiri :)
mohon maaf jika tidak ada demonya hehe :)
semoga apa yang saya sampaikan disini dapat bermanfaat bagi anda semua :D
وَ السَّلاَمُ عَلَيْكُمْ وَرَحْمَةُ اللهِ وَبَرَكَاتُهُ
